Carrier Geothermal
Suggested Retail Price From: $
Description
GCA36VTLCDET1DX1
G = Geothermal / Product
C = Tier
A = Puron Advance (R-454B) / Refrigerant
36 = 3 Ton / Nominal Cooling Capacity
V = Vertical / Cabinet Configuration’
T = Top Vert / Discharge Air Configuration
L = Left Return / Return Air Configuration
C = Copper / Coaxial Option
D = with Desuperheater / Hot Water Option
E = ECM Vaiable -Speed Constant Air Flow (VCA) / Fan Motor Option
T = Tin Plate / Air Coil Coating
1 = 208/230-1-60 / Voltage
D = with Dissipation / Dissipation System
X = Not Defined
1 = Original / Revision
FEATURES & BENEFITS
- Manage your utility costs with high-efficiency comfort (efficiency is unit size dependent): Closed loop cooling EER – Up to 27.0; Closed loop heating COP – Up to 4.4
- Optimal dehumidification capability with the Evolution™ Connex™ Control
| Attributes | |
|---|---|
| Air Flow Direction | Vertical |
| Blower Motor HP | 3/4 |
| Blower Motor Speeds | Variable |
| Blower Motor Type | ECM (Electronically Commutated Motor) |
| Blower Wheel Diameter | 11″ |
| Blower Wheel Width | 9 |
| Brand | Carrier®, Bryant® |
| COP | 4-6.2 |
| Color | Gray |
| Compressor Type | Scroll |
| Cooling Capacity | 27,000-40,500 |
| Cooling Rated Capacity (Btu/h) | 36000 |
| Country of Origin | USA |
| Cycle/Hertz | 60 Hz |
| Drain Connection Size | 3/4″ |
| EER | 16-30 |
| Energy Star Rated | YES |
| Heating Capacity | 22,000-44,000 |
| Locked Rotor Amps (LRA) | 90 |
| Maximum Overcurrent Protection (MOCP) | 40 |
| Metering Device | TXV/TEV – Thermostatic Expansion Valve |
| OPT Code | 1PGCA36VTLCDET1DX1 |
| Phase | Single |
| Product Family | GCA |
| Prop 65 | YES |
| Rated Load Amps (RLA) | 14.6 |
| Refrigerant | R-454B |
| Return Air Filter Size (RA) in Inches (W x H x D) | 24 x 30 x 1 |
| Stages Cooling | 2 |
| Stages Heating | 2 |
| Tonnage | 3 |
| UPC | See Optical |
| Voltage | 208-230 VAC |
